Firecomms is a global leader in the provision of fiber optic solutions and optical transceivers, skillfully combining state-of the-art compound and silicon semiconductor technology with inventive small-scale integration
They pioneered highly efficient RCLEDs, the connectorless Optolock® transceiver, and many other innovative technologies
These technologeis transform their customers’ communications networks in multi-discipline market segments of: power & energy, industrial, transportation, medical, gaming, mil/aero and consumer.
Firecomms is jointly headquartered in Cork, Ireland and Tongxiang, China with a global footprint of distribution and logistics teams

Product Overview

100% drop in compatible and interoperable with AVAGO VersatileLink

Target Applications:

Transmitter Features:

20-years guaranteed life time due to use of RCLED-Technology (Resonant Cavity LED)
optimized coupled optical power into POF due to use of RCLED
Low current Transmitter versions available (using 3-4mA for same optical power)

Receiver Features:

Picture	Description	Datasheets & Videos
RedLink Horizontal
	DC - 1, 2, 10, 50MBd with 650nm RCLED 1MBd long reach with 530nm RCLED Analog Tx and Rx Dual supply Voltage 3.3V / 5V open collector Version up to 20V available industrial temperature range pin compatible and interoperable with AVAGO	Datasheet Video RedLink
RedLink Vertical
	DC - 1, 2, 10, 50MBd with 650nm RCLED 1MBd long reach with 530nm RCLED Analog Tx and Rx Dual supply Voltage 3.3V / 5V open collector Version up to 20V available industrial temperature range pin compatible and interoperable with AVAGO	Datasheet Video RedLink
RedLink Tilted
	DC - 1, 2, 10, 50MBd with 650nm RCLED 1MBd long reach with 530nm RCLED Analog Tx and Rx Dual supply Voltage 3.3V / 5V open collector Version up to 20V available industrial temperature range pin compatible and interoperable with AVAGO	Datasheet Video RedLink
OptoLock Transceiver
	10-100Mbps and 10-250Mbps RSSI version SD version Analog Tx and Rx DC - 50MBd Dual supply Voltage 3.3V / 5V industrial temperature range	Datasheet Video OptoLock
LC Transceiver
	10-100Mbps and 10-250Mbps RSSI version SD version DC - 50MBd Dual supply Voltage 3.3V / 5V industrial temperature range	Datasheet Video LC Transceiver
