RV-3032-C7

• Interface: I2C
• High Time-Accuracy:
  •  ± 2.5 ppm (-40 to +85°C)
  •  ±20 ppm (+85 to +105°C)
• Ultra-Low Power-Consumption: 160 nA @ 3 V at 25 °C
• Wide Timekeeping Voltage: 1.3V to 5.5V
• Automatic Backup Switchover
• Timer, Alarm and Externel Event Functions
• AEC-Q200 available

RV-5028-C7

• Medical Implantable
• Interface: I2C
• High Time-Accuracy: - ± 1 ppm at 25°C
• Ultra-Low Power-Consumption: 45nA @ 3 V
• Wide Operating Voltage: 1.1V to 5.5V
• Automatic Backup Switchover
• Timer, Alarm and Externel Event Functions with Time Stamp Dunction

RV-3028-C7

• Interface: I2C
• High Time-Accuracy: - ± 1 ppm at 25°C
• Ultra-Low Power-Consumption: 45nA @ 3 V
• Wide Operating Voltage: 1.1V to 5.5V
• Automatic Backup Switchover
• Timer, Alarm and Externel Event Functions with Time Stamp Dunction
• AEC-Q200 available

RV-8803-C7

• Interface: I2C
• High Time-Accuracy: - ± 7 ppm at +85 to +105°C
• Ultra-Low Power-Consumption: 240nA @ 3 V
• Wide Operating Voltage: 1.5V to 5.5V
• Timer, Alarm and Externel Event Functions with Time Stamp Dunction
• AEC-Q200 available
