HTU31D

Picture Description Characteristics Features Applications Links
Digital Relative Humidity sensor with Temperature output
  • Fully calibrated, temperature compensated
  • Voltage supply range from 3V to 5.5V
  • Typical accuracy ±2%RH and ±0.2°C
  • Fast response time
  • Compact 6-Pin DFN package
  • Fast I²C interface with 2 configurable addresses
  • Qualified according to AEC Q100 grade 1 standard
  • Typical power consumption down to 3.78µW
  • High reliability and environmental robustness
  • Full interchangeability with no calibration required in standard conditions
  • Quick recovery after long periods in saturation phase
  • Compatible with automatic assembly processes
  • Reflow solderable
  • Individual marking for compliance to stringent traceability requirements
  • Lead free sensor
  • Low power consumption
  • Home Appliance
  • Medical
  • Printers
  • Humidifier
  • Automotive
  • Meteorology
  • Environmental Monitoring
Datasheet


Sales Card


Presentation

Products

Flow Sensors

Mass Air Flow Sensors

Product Package Type Operating Temp. Dimensions
(mm)		 Unique Features Calibration/Accuracy Typical Applications Links
LMM-H03 Hybrid
  • Hot film anemometer component
  • Bidirectional
 -40°C to 125°C 23 x 10.15 x 1.3
  • High sensitivity at low heater temperatures
  • Fast response time
  • True air temperature sensor
 Dependent on electronics Air intake of combustion engine, spirometer, industrial gas flow
Datasheets


Catalog

Flow Switches

Product Package Type Operating Temp. Dimensions Unique Features Typical Applications Max Pressure Links
FS-01 Noryl Flow switch for direction of liquid and gas flow -30°C to 85°C 106 x 32 x 32
  • Triac
  • Normally open
  • Close on flow
  • Mains water control
  • Power shower
  • Central heating systems
  • Circulation pump protection
  • Cooling systems
 10 bar at 20°C
Datasheets


Catalog
FS-02
  • SPST reed switch
  • Normally open
  • Close on flow
FS-05 Brass -30°C to 100°C 113 x 53 x 36
  • Triac
  • Normally open
  • Close on flow
FS-06
  • SPST reed switch
  • Normally open
  • Close on flow
FS-90/1 Cooper -30°C to 85°C 153 x 25 x 16
  • SPST reed switch
  • Normally open
  • Close on flow
  • Leak detection
  • Flow sensing
  • Mains water control
  • Cooling systems
  • Circulation pump protection

Force Sensors



Force Load Cells

Series/Model Description Specifications Features Datasheets
FMT Load Washer Cell
  • High Temperature on Request
  • Washer load cell
  • Range 20 kN to 320 kN [4.5 klbf to 71.9 klbf]
  • Ranges compatible with screw dimensions
  • High stiffness
  • Screw dimensions
  • Compression
  • For Static and Dynamic Applications
  • Support Washer Provided
FN1010 Load Pin
  • Range from 10 kN to 2000 kN (2 klbf to 400 klbf)
  • Standard and custom load in designs
  • Tension and compression uses
  • Other Ranges on Request
  • Bidirectional versions available
  • Accuracy 1% FS
  • High Coefficient of Security
  • Watertight optional
  • Level Output Model with Integrated Amplifier
FN2420 Compression Load Cell
  • Compression Design
  • Ranges from 20 kN to 5000 kN [4.5 klbf to 1124 klbf]
  • Very High Stiffness
  • Optional Build in Amplifier
  • Linearity: <0.1% F.S.
  • Integrated Amplifier optional
  • Optional: Load Button
FN3000 Load Cell Tension and Compression
  • Heavy duty Pan-cake load cell
  • Standard ranges 10 kN to 1000 kN [2 klbf to 200 klbf]
  • Very high stability
  • Aluminum or Stainless steel body
  • High IP protection available
  • High Level Output Model with Integrated Amplifier
  • Static and dynamic applications
  • Linearity 0.1% F.S.
  • Integrated Amplifier optional
  • IP65 optional
FN3002 Load Cell Tension and Compression
  • Standard ranges 10kN to 2000kN or [2 klbf to 400 klbf]
  • Harsh industrial environment
  • Very high stability
  • Stainless steel or aluminum
  • IP protection available
  • High level output with integrated amplifier
  • Static and dynamic applications
  • Rod end available in option
  • Integrated Amplifier optional
  • IP65 optional
FN3030 Load Cell Tension and Compression
  • S-Beam Load Cell
  • 50 N to 100,000 N (11.2 lbf to 22,480 lbf)
  • Stainless Steel or Aluminum
  • Cable Gland or Connector Output
  • Built In Amplifier per Request
  • Optional Rod Ends
  • Accuracy: 0.1% F.S.
  • Integrated Amplifier optional
  • Low Cost
FN3042 Load Cell for Fatigue Testing
  • Heavy duty cylindrical load cell
  • Ranges from 5 kN to 500 kN [1.124 klbf to 112.4 klbf]
  • Tension and Compression
  • Suited for fatigue and crash testing
  • High Level Output with Integrated Amplifier
  • High stiffness
  • Accuracy: 0.25% F.S.
  • Skydrol compatible on request
  • Integrated Amplifier optional
FN3050 Load Cell Tension and Compression
  • Range from 100 N to 20000 N (22.5 lbf to 4496 lbf)
  • Accuracy: 0.1% F.S.
  • Stainless steel or aluminum
  • Connector or cable gland output
  • Build in amplifier per request
  • Same housing for all ranges
  • Mechanical stops in option
  • Optional: Tension Pull Plate, Load Button
  • Integrated amplifier optional
FN3148 Load Cell with Mechanical Stops
  • Ranges from 10 N to 2 000 N [2.25 lbf to 450 lbf]
  • S-Beam sensor in tension and compression
  • Combined linearity & hysteresis < 0.05% F.S.
  • High accuracy
  • Integrated Amplifier optional
  • Cable or connector output
FN3280 Low Range Load Cell with Mechanical Stops
  • Very low range: 1 N to 5 N (0.2 lbf to 1 lbf)
  • S-Beam with mechanical stops
  • Very high resolution
  • Combined non-linearity & hysteresis 0.1% F.S
  • High accuracy
  • Tension and Compression
  • Integrated Mechanical Stops
  • Full Wheatstone bridge
  • Cable output
FN9040 Press-fit Load Cell
  • Ranges from 0-1 kN to 0-100 kN
  • Deflection at full scale < 50µm
  • Natural frequency > 20 kHz
  • Global accuracy < 1% FS
  • Small size
  • Spherical load button
  • Easy Installation
FN9620 Force Load Cell
  • High tensile strength Stainless Steel
  • Quick availability & stock
  • Ranges from ±500N to ±10,000N
  • Non-linearity ±0.05% FS
  • -40 to 90°C temperature operating range
  • Integral shielded cable
  • High tensile strength Stainless Steel
  • Metric or Imperial thread
  • Surcharge sans destruction 300%
  • Safe over load 300%
  • 3 meters Integral cable
  • IP68-1m water column

Multiaxial Load Cells

Series/Model Description Specifications Features Datasheets
FN7110 Double Range Load Cell
  • Double S-Beam Load Cell
  • 10/100 N to 1k/10k N (2/20 lbf to 200/2k lbf)
  • High resolution
  • For compression and traction uses
  • Double Full Scale Range
  • Accuracy : 0.1% F.S. for each range
  • Integrated Mechanical Stops
  • Integrated Amplifier optional
FN7325 Multiaxial Load Cell
  • 6-Components Load Cell
  • Force range from 5 kN to 250 kN (1 klbf to 50 klbf)
  • Measures force in three directions X, Y, Z
  • Measures torque in three directions Mx, My, Mz
  • Minimal Cross Effects
  • Measures force & torque simultaneously
  • Up to 6 components load cell
  • Multiple and custom designs available
  • Integrated amplifier optional

Miniature Load Cells

Series/Model Description Specifications Features Datasheets
XFC200R Compression Miniature Load Cell
  • Range from 0-2N to 0-10kN [0-0.45 lbf to 0-2.2 klbf]
  • High Stiffness
  • Integrated Spherical Load Button
  • Linearity < 0,5% FS
  • High accuracy for low ranges
  • Integrated Spherical Load Button
  • High Overload Capacity
  • Small design
XFC205R Miniature Load Cell in Compession
  • Ranges from 0-2 to 0-200N [0-0.45 to 0-45 lbf]
  • Important Overload Capacity
  • Linearity < 0.5% FS
  • Easy Installation with Threaded M5 Male Base
  • Integrated Spherical Load Button
  • High IP rating on request
  • Other thread and design on request
XFL212R Compression Miniature Load Cell
  • Ranges from 0-5 to 0-500N [0-1.12 to 112 lbf]
  • Extremely Flat 3,5 mm [0.14”]
  • Diameter Only 12 mm [0.49”]
  • Integrated Spherical Load Button
  • Load Washer Model
  • Flat sensor
  • High Stiffness
  • Integrated Spherical Load Button
  • Other designs available on request
XFL225D Compression Miniature Load Cell
  • 0-10 N to 0-5 kN [0-2.25 lbf to 0-1.12 klbf]
  • Diameter 25mm [0.98”]
  • For Static and Dynamic Applications
  • Strain Relief Spring
  • Load Washer Model
  • Flat sensor
  • Inside hole ∅ 8mm or flat surface
  • Temperature compensated
XFTC300 Miniature Load Cell
  • Ranges 0-2N to 0-2kN [0.45 lbf to 450 lbf]
  • High Stiffness
  • Threaded Male Mechanical Fitting
  • Linearity < 0,5% FS
  • Tension and/or Compression
  • Small design easy to mount
  • Wide temperature range in option
  • Amplifier Integrated optional
  • Easy to customize signal and design
XFTC301 Miniature Load Cell
  • 0-500N to 0-10kN [112.4 lbf to 2.248k lbf]
  • High Stiffness
  • Threaded Male Mechanical Fitting
  • Linearity < 0,5% FS
  • Tension and/or Compression
  • Small design easy to mount
  • Wide temperature range in option
  • Very small size
XFTC302 Miniature Load Cell High Temperature
  • Range from 0-5kN to 0-10kN [0-1.124klbf to 2.148klbf]
  • Tension and Compression
  • High Temperature Range : -55 to +175° C [-67 to +347° F]
  • Wide temperature compensation range
  • Optional IP rating improvement
  • Heavy duty
  • Integrated Amplifier optional
  • Easy to customized signal and design
XFTC310 Miniature Load Cell
  • Range from 0-2N to 0-2KN [0.45 lbf to 450 lbf]
  • Tension and Compression
  • High Overload Capacity
  • Small design easy to mount
  • Optional IP rating improvement
  • Extended temperature range available
  • Other male/female threads available
XFTC311 Miniature Load Cell
  • Range from 0-500N to 0-10kN [0-112.4lbf to 2.248klbf]
  • Tension and Compression
  • Linearity ≤ ± 0.5% FS
  • Male/female M5 and M10 threaded
  • Optional IP rating improvement
  • Extended temperature use as option
XFTC320 Miniature Load Cell
  • Ranges from 0-2N to 0-2kN [0.45 lbf to 450 lbf]
  • Tension and Compression
  • High Overload Capacity
  • Heavy duty
  • Sealed version available as option
  • Integrated Amplifier optional
XFTC321 Miniature Load Cell
  • Range from 0-500N to 0-10kN [0-112.4 lbf to 2.2481 klbf]
  • Tension and/or Compression
  • Threaded Female Mechanical Fitting
  • Aluminum or stainless steel body
  • Tension and Compression
  • Heavy duty
  • Sealed version optional
  • Easy to customize threads
XFTC322 Miniature Load Cell
  • Range from 0-5kN to 0-10kN [0-1.124 klbf to 2 .248klbf]
  • Tension and/or Compression
  • High Temperature Range : -55 to 175 ° C [-67 to 347 ° F]
  • Wide range of temperature compensated
  • Optional IP rating improvement
  • Heavy duty
  • High stiffness
XFU400 Miniature Load Cell
  • Range from 0-500 N to 0-5 kN or [100 lbf to 1 klbf]
  • Tension and Compression
  • Low deflection
  • Based on standard rod end bearings
  • Easy to integrate
  • Fast response time

OEM Compression Load Cells/ Tension Load Cells

Series/Model Description Specifications Features Datasheets
ELAF LOAD CELL Load Cell
  • Compact Design: 12.7mm [0.5”], 15.88mm [0.625”] and 31.75mm [1.25”] Diameter
  • Compression/Tension
  • Stainless Steel Body
  • 50 – 10KN [10 – 2000lbf]
  • Amplified or mV Output
  • Temperature Compensated
  • High Stability
  • Industry Standard Packaging
  • Resists Off Axis Load Components
  • Full NIST Traceable 11 Point Calibration
  • Shielded FEP/PTFE Cabling with Strain Relief
  • Variety of Options Available
  • IP65 Weatherproof
  • Low Cost
  • Optional High Level Output
  • Small, Low Profile Design
  • Low Noise
  • Robust: High Over Range
  • High Reliability
  • Low Deflection
  • Low Off-Axis Response

Humidity Sensors


Flyer Humidity Sensor Overview

Humidity and Temperature (NTC) Components

Product Package Type Operating Temp. Unique Features Accuracy Dimensions
(mm)		 Typical Applications Operating RH Range Links
HS1101LF Through hole TO39 with side opening plastic cap Capacitive humidity -60°C to 140°C
  • Robust and recognized component
  • Suitable for most humidity applications
  • Cost effective solution
 180 pF, ±3 pF at 55% RH 10 x 10 x 19 Applications requiring a robust humidity sensor in appliance:
  • HVACR
  • Consumer electronics
  • Printing
  • Meteorology
 0 to 100% RH
Datasheets


Catalog
HTU2X DFN type Digital RH and NTC temperature -40°C to 125°C
  • Low power consumption
  • Fast response time
  • Very low temperature coefficient
  • I2C interface or PWM interface or SDM interface
 ±3% RH at 25°C (10 to 95% RH) ±0.3°C at 25°C 3.0 x 3.0 x 1.0 Humidity and temperature plug and play transducers for OEM demanding applications in appliance:
  • Printer
  • Medical
  • HVACR
HTU2XF
  • Low power consumption
  • Fast response time
  • Very low temperature coefficient
  • I2C interface or PWM interface or SDM interface
  • Optimal filter

Humidity and Temperature (NTC) Mini-Modules

Product Type Unique Features Dimensions Operating RH Range Operating Temp. Calibration Package Typical Applications Links
HTU3535PVBM/Wire Analog voltage RH and NTC temperature
  • PTFE filter (Optional)
  • Electronics fully protected (5 V)
  • Multiple connector choices (JST, Samtec board to board through hole)
  • Based on HTU21
 27 x 11.9 x YY
(Depending on the connector, from 6 to 10.8 mm length)		 0 to 100% RH -40°C to 110°C ±3% RH at 55% RH; ±0.25°C at 25°C Cost effective small size mini-module Humidity and temperature plug and play transducers for OEM demanding applications in:
  • HVACR
  • Home appliance
  • Printer
  • Medical
Datasheets


Catalog
HTU383X/Wire Digital RH and NTC temperature
HTG351xCH Analog voltage RH and NTC temperature
  • Electronics fully protected with potting material (3.3 V or 5 V)
  • Multiple connector choices (JST, Samtec board to board through hole)
 27 x 11.9 x 6.7

Humidity and Temperature (NTC) Probes

Product Package Type Dimensions
(mm)		 Calibration Operating Temp. Typical Applications Unique Features Operating RH Range Links
HM1500LF Probe, RH only Cost effective analog voltage RH probe 57 x 11 x 11
(Standard wire length of 200 mm)		 ±3% RH at 55% RH -40°C to 60°C
  • Medical
  • Telecommunication cabinets
  • Green houses
  • Process control
  • Industrial
  • Electronics fully protected with potting material
  • Optional wiring length and connectors
 0 to 100% RH
Datasheets


Catalog
HM1520LF Dedicated to low RH accurate measurement 57 x 11.5 x 11.5
(Standard wire length of 200 mm)		 ±3% RH at 10% RH
  • Medical
  • Drying cabinets
  • Low humidity
  • Meteorology
HM2500LF Probe, RH and temperature Cost effective analog voltage RH 86 x 11.5 x 11.5
(Standard wire length of 200 mm)		 ±3% RH at 55% RH; ±0.25°C at 25°C -40°C to 85°C
  • Hygrostat
  • Data loggers
  • Cabinets

Humidity and Temperature (NTC) Sensors

Product Package Type Operating RH Range Operating Temp. Unique Features Calibration Dimensions
(mm)		 Typical Applications Links
HTF3000LF PCB for board to board Frequency output for RH, direct NTC for temperature 0 to 100% RH -40°C to 85°C
  • Voltage supply from 3 to 8 VDC
  • Through hole or SMD
  • T and R available
 ±3% RH at 55% RH; ±0.25°C at 25°C 12.5 x 18.5 x 11.2
  • HVACR
  • Printer
  • Cabin comfort
  • Hygrostat
Datasheets


Catalog

Liquid Level Switches

Type Category Product Package Unique Features Max Pressure Operating Temp. Dimensions Typical Applications Links
Level Sensor Side Entry LS304-31 Glass filled nylon 6.6 1/2" NPT horizontal mount SPDT 4.7 bar -30°C to 130°C 103 x 29 x 29
  • Chemical high or low level
  • Diesel fuel
  • Fuel low level
  • Alcohols
  • Low oil detection
Datasheets


Catalog
LS509-51 Glass filled PPS M16 horizontal mount SPST 4.7 bar -30°C to 110°C 88 x 27 x 27
  • Coolant level indication
  • Water high or low level
  • Boiler heating element protection
  • Drinking water level
  • Boiling water
LS809-31 Glass filled polypropylene 1/2" NPT horizontal mount SPST 2.0 bar -30°C to 105°C 103 x 29 x 29
  • Continuous 80°C in water
  • Water high or low level
  • Condensate level alarm
  • Drinking water level
  • Cooling systems
LDS309-11N Glass filled nylon 6.6 M16 horizontal mount SPST 4.7 bar -30°C to 130°C 100 x 27 x 27
  • Chemical high or low level
  • Diesel fuel
  • Fuel low level
  • Alcohols
  • Low oil detection
LCS-03 Acetal/Polypropylene Push fit horizontal mount SPST 0.34 bar -30°C to 60°C 100 x 36 x 36
  • Water high or low
  • Unpressurized central heating systems
  • Fuel level
  • Organic solvents
RCS-01-10 Polypropylene M16 Horiz mount SPST 4.7 bar -30°C to 70°C 67 x 30 x 30
  • Waste water level
  • Coolant
  • Water
Top & Bottom Entry VS309-51N Glass filled nylon 6.6 M16 vertical mount SPST 4.7 bar -30°C to 130°C 87 x 22 x 22
  • Chemical high or low level
  • Diesel fuel
  • Fuel low level
  • Alcohols
  • Low oil detection
VS804-21 Glass filled polypropylene M16 vertical mount SPDT 4.7 bar -30°C to 105°C 87 x 22 x 22
  • Continuous 80°C in water
  • Water high or low level
  • Condensate level alarm
  • Drinking water level
  • Cooling systems
VCS-04 Polypropylene M8 vertical mount SPST 1.3 bar -30°C to 70°C 59 x 22 x 22
  • Water high or low
  • Condensate level
  • Cooling sytems
VCS-06 Nylon 6.6 M8 vertical mount SPST 1.3 bar -30°C to 105°C 59 x 22 x 22
  • Chemical high or low level
  • Diesel fuel
  • Fuel low level
  • Alcohols
  • Low oil detection
EVS312-11N Nylon 6.6 M16 vertical mount 2 X SPST 4.7 bar -30°C to 110°C 224 x 22 x 22
  • Chemical high or low level
  • Diesel fuel
  • Fuel low level
  • Alcohols
  • Low oil detection
EVS722-51 Brass/ Polypropylene M16 vertical mount 16 X SPST 4.7 bar -30°C to 80°C 224 x 22 x 22
  • Coolant level indication
  • Water high or low level
  • Boiler heating element protection
  • Sump level

Piezo Film Sensors

Piezo Film

Product Package Type Range Unique Features Accuracy Operating Temp. Dimensions
(mm)		 Links
DT1, SDT1 Unshielded element with twisted pair or shielded element with shielded cable Flexible film, adhesive mount 15 mV/µε up to 1% strain
  • Thin, flexible, robust
  • Withstands >2% strain
  • Ultra-low power (Self generating)
 ±20% (Typical) -40°C to 70°C
(Higher available custom)		 Application dependent
Datasheets


Catalog
Piezo Cable Shielded coaxial 20 gage piezo cable Polymer jacketing,
armored jacketing		 μPa sensitivity
  • Continuous lengths of up to 1 km
  • Shielded construction
 ±20% (Typical) -40°C to 85°C Ø3 (Continuous lengths)
CM-01 Metallized plastic housing Contact microphone 40 V/mm; 8 Hz to 2.2 kHz
  • Low noise
  • Shielded construction
  • High sensitivity
 - 5°C to 60°C Ø18 x 11 high
FLDT1 Unshielded film element with screen printed leads Flexible film,
adhesive mount		 15 mV/µε, up to 1% strain
  • Thin, flexible
  • Leads screen printed on film
  • Connects to standard connector
 ±20% (Typical) -40°C to 70°C
(Higher available custom)		 12 x 30 active
(Custom available)
Sleep Monitor Strip Unshielded element with crimps Flexible film,
adhesive mount		 15 mV/µε up to 1% strain
  • Thin, flexible, robust
  • Withstands >2% strain
  • Ultra-low power (Self generating)
 ±20% (Typical) -40°C to 70°C
(Higher available custom)		 28 um PVDF; 8mm x 800mm
Laboratory Amplifier Bench top Piezo film lab amp 0.1 Hz to 100 kHz
  • Voltage or charge mode settings
  • Multi-pole high-pass and low-pass filters
  • Adjustable gain
 Application dependent 0°C to 40°C 150 x 100 x 100
80 KHz Transducers Pin mounted Air ultrasound transducer 80 kHz
  • Small size
  • Low mechanical Q
  • Shielded package
 Application dependent -20°C to 80°C Ø6 x 9
NDT-1 Adhesive mounted High frequency ultrasound transducer 3 MHz
  • Flexible
  • High bandwidth, low Q
  • Low impedance
 Application dependent -20°C to 60°C 12 x 30
ACH-01 Ceramic base, plastic cover, shielded cable Adhesive mount ±250 g (Typical)
  • Extremely high bandwidth
  • Low cost
  • Ultra-low power
 ±20% (Typical) -40°C to 85°C 18.80 x 13.21 x 6.10
LDTC Family Piezo film elements with or without mass Cantilever beam with vertical or horizontal pins ±10 g (Typical)
  • Very low cost
  • High sensitivity (1 V/g)
  • Ultra-low power (Self generating)
 ±20% (Typical) -40°C to 70°C 19.05 x 6.35 x 6.35
Metallized Piezo Film Sheets Available in different film sizes and thicknesses Thin, flexible film sheets
  • Thin, flexible film sheets
  • Multi-purpose … design your own Sensor
  • Different electrode options – sputtered metallization or silver ink
  • Various film thickness options
 8” x 5.5” and 8” x 11”

Position Sensors

Anisotropic Magnetroresistive (AMR) Sensor Components

Product Package Type Range Unique Features Output Resolution Accuracy Operating Temp. Dimensions
(mm)		 Links
KMY, KMZ SOT-223, E-line 4 pin Linear low field sensor -2 to 2 kA/m magnetic field
  • High sensitivity
  • Low hysteresis
  • Linear to uniaxial field strength
 Ratiometric with output voltage range 20 mV/V Typ. 0.1% of range Typ. 1.0% of range -40°C to 150°C SOT: 6.6 x 7.0 x 1.6 E-line: 16 x 4.2 x 2.4
Datasheets


Catalog
MS32 TDFN Low field switch sensor 1 to 3 kA/m magnetic switching field
  • Linearized ratiometric output
  • Temperature compensated switching point
 Ratiometric with output voltage range 10 mV/V Typ. 0.1 kA/m Typ. 0.1 kA/m -25°C to 85°C TDFN: 2.5 x 2.5 x 0.8
KMT39, KMT37 TDFN Angle sensor 180° angle
  • High accuracy
  • High resolution
 Sine and cosine signals with output voltage range 20 mV/V Typ. 0.01° to 0.1° Typ. 0.1° to 1.0° -40°C to 150°C
(175°C on request)		 TDFN: 2.5 x 2.5 x 0.8 SO-8: 5 x 4 x 1.75
KMT36H TDFN 2.5 x 2.5 Angle sensor 360° angle
  • High accuracy
  • High resolution
  • 360° full turn
 Three 120° phase shifted output signals with output voltage range 20 mV/V Typ. 0.01° to 0.1° Typ. 0.1° to 1.0° -40°C to 150°C TDFN: 2.5 x 2.5 x 0.8
KMXP DFN 2 x 6 Linear displacement sensor,
3 flat and 3 perpendicular versions 		Absolute within magnetic pole pitch,
else incremental
  • For pole pitch
  • KMXP 1000: p= 1 mm
  • KMXP 2000: p= 2 mm
  • KMXP 5000: p= 5 mm
 Sine and cosine signals with output voltage range 20 mV/V 0.01% to 0.1% of pole pitch 0.1% to 1.0% of pole pitch -40°C to 125°C° DFN: 2 x 6 x 0.8
KMA36 TSSOP Angle sensor with digital output 360° angle
  • Low cost MR encoder for rotational and incremental measurements
  • Digital output
 Analog and I²C Digital Typ. 0.1° Typ. 0.3° -25°C to 85°C TSSOP20: 6.5 x 6.4 x 1.2
MLS (Hybrid) HD
HS		 Magnetic linear position sensor 1, 2, 5 (mm)
  • Very high precision
  • Insensitive to air gap fluctuations
  • Highly reliable
  • Low interference field sensitivity
 Passive Analog <1% of the pole pitch per meter High accuracy / low hysteresis -40°C to 85°C HD: 7.5 x 5.2 x 0.63
HS: 17.8 x 8.15 x 1.02

Angular Position Transducers-Inductive

Product Package Resolution Excitation Output Range Unique Features Operating Temp Dimensions
(mm)		 Links
R60D Servo mount with ball bearing Infinite DC symmetrical ±15 VDC ±7.5 VDC ±60°
  • Absolute position
  • Low momentum of inertia
 -25°C to 85°C Aluminum case size 11 (Ø27 mm)
Datasheets


Catalog
R30A Servo mount with ball bearing AC operated AC voltage ±30° to ±60°
  • Absolute position
 -55°C to 150°C Aluminum case size 11 (Ø27 mm)
RS36AS Servo mount,
an MS style hermetic connector,
and a shaft seal		 AC operated AC voltage ±60°
  • High accuracy
  • Shielded ABEC 3 precision bearings
 -55°C to 150°C Stainless steel housing size 15 (Ø38.1mm)
R30D Rugged aluminum DC operated bipolar ±15 VDC ±60°
  • Bipolar DC operation
  • Light-weight
 -18°C to 70°C Aluminum case size 11 (Ø27 mm)
RVIT 15-60 & 15-120i Rugged aluminum DC operated ±3 VDC ±120°
  • Extremely long rotational life
  • Internal voltage regulation
 -18°C to 77°C Aluminum case size 15 servo or flange mount
R120LC Anodized aluminum DC operated 0.5 to 4.5 VDC ±120°
  • Precision ball bearings
  • Low moment of inertia
-25°C to 85°C Shaft Diameter: Ø6.3 mm

Tilt Sensors

Category Product Package Type Range Output Unique Features Accuracy Operating Temp Dimensions Links
Single Axis E-Series Ceramic housing Inclination sensor module ±5°, ±15° Voltage
  • Easy to handle
  • Minimal temperature drift
  • Good long term stability
 ±0.2° to ±0.5° -25°C to 85°C 29 x 17 x 16.5
Datasheets


Catalog
AccuStar EA LCP housing Inclinometer sensor module ±45° to ±60° Voltage
  • Compact
  • Low power
  • Vertical and horizontal mount
 0° to 10° ±0.1% accuracy
10° to 60° ±0.75% reading 		-30°C to 65°C 65.91 x 51.56 x 30.5
APS System Plastic housing Inclination system ±45°, ±90° Analog / digital
  • Stand alone system
  • Separate system and sensor
 0° to 10° ±0.1% accuracy
10° to 45° ±0.75% of reading		 -25°C to 65°C 127.5 x 88 x 32.2
AccuStar IP66 Aluminum housing IP66 Inclinometer ±3° to ±45° Current
  • EMI and RFI rated
  • CE pending
  • Water tight enclosure
 0° to 10° ±0.1% linearity
10° to 45° ±1% linearity		 -25°C to 60°C 98.04 x 63 x 35.05

Proximity Sensors

Product Package Unique Features Operating Temp. Dimensions
(mm)		 Type Typical Applications Links
PS801 Stainless steel SPST reed switch, normally open -30°C to 120°C Ø12 x 65
  • Proximity sensor
  • Used with proximity magnet
  • Door interlocks
  • Hook switches
  • Security systems
  • Safety interlocks
  • Position indication
Datasheets


Catalog
PS811 Nylon 6.6 SPST reed switch, normally open -30°C to 110°C Ø10 x 38
PS831 Stainless steel SPST reed switch, normally open -30°C to 130°C Ø12 x 32
PS2011AB Glass filled nylon 6.6 SPST reed switch, normally open -30°C to 105°C 29 x 7 x 20
PS2021AB Glass filled nylon 6.6 SPST reed switch, normally closed -30°C to 105°C 29 x 7 x 20
PS2031AB Glass filled nylon 6.6 SPST reed switch -30°C to 105°C 29 x 7 x 20
PS501 Glass filled nylon 6.6 SPST reed switch, normally open -30°C to 130°C Ø6 x 32

Proximity Magnet

Product Package Operating Temp. Dimensions
(mm)		 Type Unique Features Typical Applications Links
PM101 Glass filled nylon 6.6 -30°C to 105°C 29 x 7 x 20
  • Proximity magnet
  • Used with proximity sensor
 Housed magnet
  • Door interlocks
  • Hook switches
  • Security systems
  • Safety interlocks
  • Position indication
Datasheets


Catalog
PM50 Glass filled nylon 6.6 -30°C to 70°C Ø6 x 32
PM81 Nylon 6.6 -30°C to 120°C Ø10 x 38
PM83 Stainless steel -30°C to 120°C Ø12 x 32

Linear Position Transducers-Inductive

Category Product Package Linearity Excitation Output Diameter
(mm)		 Unique Features Links
Absolute HR AISI-400 series stainless steel ±0.25% of range AC operated AC voltage 20.6
  • Large bore to core clearance
  • Broad range of excitation frequencies
  • Variety of options
  • Mild radiation resistance option
Datasheets (Coming Soon)


Catalog
M12 AISI-304 series stainless steel ±0.25% of range AC operated AC voltage 12
  • Metric series
  • High stroke to length ratio
  • Constant sum of secondaries
  • Excellent temperature coefficient
HC AISI-400 series stainless steel ±0.25% of range AC and DC operated versions AC or DC voltage,
4 - 20 mA loop or RS-485		 19
  • Hermetically sealed
  • Welded connector
  • Double shielding
  • Intrinsically safe version
  • CE mark for DC versions
XS-C AISI-304 series stainless steel ±0.25% of range AC operated AC voltage 19
  • High pressure
  • Bulkhead mounting
  • Hermetically sealed welded assembly
DC-SE AISI-400 series stainless steel ±0.25% of range 8.5 to 28 VDC 0 - 5 VDC (4 wire),
1 - 6 VDC (3 wire)		 19
  • CE mark
  • Low current consumption (6 mA typical)
  • Synchronous demodulation
  • Shielded cable
XS-D AISI-400 series stainless steel ±2% of range AC operated AC voltage 20.6
  • Very high stroke to body length ratio
Dimensional Gaging Products LBB Spring-Extend - ±0.2% of range AC operated AC voltage 8 or 9.5
  • 0.000004 inch (0.1 μm) repeatability
  • Removable tungsten carbide contact tip
  • Double shielded LVDT
  • Repairable
LBB Air-Extend - ±0.2% of range AC operated AC voltage 8 or 9.5
PCA375 - ±0.5% of range AC operated AC voltage 9.5
  • Longer strokes
  • IP65 cable exit
  • Accepts industry standard contact tips
  • Heavy duty return spring
GC - ±0.25% (Voltage) to ±0.5%
(4 - 20 mA) of range		 AC or DC voltage AC or DC voltage, RS485, or 4 - 20 mA loop 19 mm body,
1/2 - 20 threads
  • Hermetically sealed
  • Welded MS connector (MIL-C-5015) "
  • CE mark for DC versions
  • Special tips available
  • Air extend spring retract available
Ultimate Precision - Accuracy ±0.2% 5 VDC USB (Bus or external) RS485; USB Stackable gage system
  • Plug-and-play
  • 14-bit resolution
  • COM libraries provided
  • CE mark
  • USB adapter and power supply available

LVDT / RVDT Instrumentation

Product Package Supply Output Operating Temp. Dimensions
(mm)		 Unique Features Links
LVM-110, LiM-420 Open circuit board DC voltage DC voltage or current 0°C to 55°C 63 x 56 x 21
  • Master/slave for multi-up applications
  • Dip switch selectable excitation frequencies
  • Plug-in PCB or wire termination
  • Small form factor
Datasheets


Catalog
LDM-1000 DIN rail mount 10 to 30 VDC DC voltage or current -25°C to 85°C 115 x 99 x 23
  • Operates with 4, 5 & wire LVDT/RVDTs
  • Adjustable zero, span and phase
  • Status LEDs
  • CE mark
ATA-2001 1/8 DIN panel mount 115 and 220 VAC,
50 - 400 Hz		 DC voltage or current -40°C to 85°C 267 x 99 x 49
  • Push button programmable
  • Splash proof front panel
  • LED status lights
  • Mounting hardware included
  • CE mark
MP 2000 1/4 DIN panel mount 100 to 240 VAC,
47 - 63 Hz		 DC voltage and RS-232 0°C to 55°C 178 x 92 x 92
  • Programmable set point controller
  • Dual channel with math functions
  • Digital I/O
  • Large LCD display
  • Splash proof front panel
PSD 40-15 DIN rail mount 85 to 264 VAC
45 to 65 Hz		 DC voltage -25°C to +70°C 113.6 x 99 x 45.2
  • 115/230 VAC input
  • 45 to 65Hz input frequency
  • Low noise output
  • Overload and short circuit protection
  • ±15 VDC outputs
  • 1 AMP continuous output current
  • DIN rail mount for easy installation
  • Rugged design

Pressure Sensors


Flyer Pressure Sensor Overview

Board Level Pressure Sensors

Category Product Package Type Pressure Range Output/Span Resolution Overpressure Dimensions
(mm)		 Links
Digital Output and Altimeter MS4515DO
MS4525DO		 8 pin DIL Gage, compound (MS4515DO)
Gage, absolute, differential, compound (MS4525DO)		 0 - 2 to 30" H2O (MS4515DO)
0 - 1 to 150 psi (MS4525DO)		 14-bit ADC SPI or I²C - 300 psi 12.5 x 9.9
Datasheets


Catalog
MS5803 Surface mountable Absolute 0 - 2 to 30 bar 24-bit ADC I²C and SPI (Mode 0, 3) 12 μbar (MS5803-01BA)
0.5 mbar (MS5803-30BA)		 10 bar (1, 2 bar)
30 bar (5, 7, 14 bar)
50 bar (30 bar)		 6.4 x 6.2 x 2.9
MS5837 Surface mountable Absolute 0 - 2 bar 24-bit ADC I²C 0.016 mbar (2 bar) 10 bar (2 bar) 3.3 x 3.3 x 2.75
MS5840 Surface mountable Absolute 0 - 2 bar
Operating range: 300 to 1200 mbar		 24-bit ADC I²C 13 cm of air - 3.3 x 3.3 x 1.7
MS5525DSO SOIC-14 Gage, absolute, differential, compound 0 - 1 to 30 psi 24-bit ADC SPI or I²C protocol - 3X range 12.5 x 7.9
MS5607
MS5611
MS5637		 Surface mountable Absolute 10 - 2K mbar 24-bit ADC I²C 0.016 mbar 6 bar 3 x 3 x 0.9 (MS5637)
5 x 3 x 1 (MS5607, MS5611)
MS5805 Surface mountable Absolute 10 - 2K mbar 24-bit ADC I²C 0.02 mbar 5 bar 4.5 x 4.5 x 3.5
MS8607
(Integrated pressure, humidity and temperature sensor)		 Surface mountable Absolute 10 - 2K mbar 24-bit ADC I²C 0.016 mbar 6 bar 5 x 3 x 1
Amplified Output MS4515
MS4525		 8 pin DIL Gage, differential (MS4515)
Gage, absolute, differential, compound (MS4525)		 0 - 2 to 30” H2O (MS4515)
0 - 1 to 150 psi (MS4525)		 10% to 90% or 5% to 95% of supply - - 12.5 x 9.9
MS5525ASO SOIC-14 Gage, absolute, differential, compound 0 - 1 to 30 psi 10 - 90% VDC - - 12.5 x 7.9
mV Output MS4425
MS4426		 6 pin DIL Gage, absolute, differential 0 - 1 to 300 psi 60 mV, 90 mV, 100 mV, and 150 mV typical - - 15.2 x 13.7
MS1451
MS1471		 Surface mountable Gage, absolute 0 - 5 to 500 psi 60 mV typical - - 7.6 x 7.6, application dependent

Disposable Medical Pressure Sensors

Product Package Type Pressure Range Output/Span Unique Features Operating Temp. Dimensions
(mm)		 Links
1620
1630		 Hybrid assembly Gage -30 to 300 mmHg 5 μV/V/mmHg
  • Low cost, disposable design
  • Supplied in tape and reel
  • Compliant to AAMI spec
  • ISO13485 certified
 10°C to 40°C 1620: 11.43 x 8.13 x 4.20
1630: 12.7 x 5.08 x 3.94
Datasheets


Catalog
Fully Assembled 1620 Plastic housing Gage -30 to 300 mmHg 5 μV/V/mmHg
  • Low cost, disposable design
  • Compliant to AAMI spec
  • Custom designs available
 10°C to 40°C 42.8 x 30.3 x 19.0

Media Isolated Pressure Sensor Modules

Digital Output
Product Package Type Pressure Range Output/Span Unique Features Accuracy Total Error Band Dimensions Links
85BSD
  • 13 mm diaphragm diameter
  • Weldable or threaded process fittings
 Gage, absolute 0 - 0.35 to 20 bar /
0 - 5 to 300 psi		 14-bit ADC I²C or SPI
  • Pressure and temperature read-out
  • Cable and connector options
  • Low power option
 ±0.25% span ±1.0% FSO Ø15.85 x 7.9
Datasheets


Catalog
86BSD
  • 16 mm diaphragm diameter
  • O-ring mount
 Gage, absolute 0 - 0.07 to 20 bar /
0 - 1 to 300 psi		 14-bit ADC I²C or SPI
  • Pressure and temperature read-out
  • Cable and connector options
  • Low power option
 ±0.25% span ±1.0% FSO Ø15.82 x 9.3
89BSD
  • 9 mm diaphragm diameter
  • Threaded or weldable
 Absolute, sealed gage 0 - 6 to 30 bar 24-bit ADC I²C
  • Pressure and temperature read-out
  • Low power: 1 μA (Standby < 0.15 μA)
 ±0.3% span ±3.0% FSO max. Ø9.04 x 7.5
154BSD
  • 19 mm diaphragm diameter
  • O-ring mount
 Gage, absolute 0 - 1 to 300 psi 14-bit ADC I²C or SPI
  • Pressure and temperature read-out
  • Cable and connector options
  • Low power option
 ±0.25% span ±1.0% FSO Ø19 x 13.8

Transducers and Transmitters

Industrial Wireless
Prodcut Type Pressure Range Output Span Accuracy Dimensions Unique Features Agency Approvals Links
M5600
U5600		 Gage, sealed, absolute, compound 0 – 50 to 15K psi (M5600)
0 – 5 to 10K psi (U5600)		 24-bit ADC I²C ±0.25% FS (M5600)
Down to ±0.1% FS (U5600)		 24 x 24 x 69
  • Pressure and temperature
  • 2.3 – 3.6 V supply voltage
  • Compact and battery-powered
  • Weather resistant (IP66 and IP67)
  • Stainless steel and polycarbonate enclosure
 CE, FCC
Datasheets


Catalog
MSP100 Gage 0 - 100 to 500 psi 100 mV typical ±0.5% FSO 12.7 x 24.38 x 20.32
  • Microfused
  • Low cost stainless steel isolated transducer
  • No threads needed for pressure connect
  • Highly customized for OEM application
  • Small size
  • Solid state reliability
 -
MSP300
MSP340		 Gage 0 - 100 to 10K psi (MSP300)
0 - 50 to 10K psi (MSP340)		 0 - 100 mV,
0.5 - 4.5 VDC,
1 - 5 VDC,
4 - 20 mA		 ±1% FSO MSP300: 22.23 x 22.23 x 55.88
MSP340: 15.88 x 15.88 x 75.44
  • Microfused
  • Highly customized for OEM applications
  • Small size
  • Solid state reliability
 UL 508(MSP300)

Media Isolated Pressure Sensor Modules

Analog Output
Products Package Type Pressure Range Output/Span Non-linearity Dimensions Unique Features Links
82, 85 with Fittings Weldable (85) or process fitting Gage, absolute, vacuum gage 0 - 5 to 500 psi (85),
0 - 1 to 500 psi (82)		 100 mV typical ±0.3% FSO (1 psi)
±0.2% FSO (5 psi)
±0.1% FSO (≥15 psi)		 Fittings: application dependent
  • Modular design
Datasheets


Catalog
89 Button
89 with Fitting		 Weldable or process fitting Sealed gage, absolute 0 - 1K to 10K psi 100 mV typical ±0.25% FSO 89 Button: Ø9.04 x 13.2
89 with Fittings: application dependent
  • High pressure
  • Modular design
86A Amplified 5/8” (16 mm) diameter o-ring mount Gage, absolute 0 - 1 to 150 psi 0.5 - 4.5 VDC ±1.0% FSO Ø15.82 x 9.3
  • Small diameter, amplified output
  • Bar ranges available
82, 85, 85F, 86, 154N 82, 154N: 3/4" (19mm)
86: 5/8" (16mm)
85, 85F: 1/2" (13mm)		 82, 85, 86, 154N: Gage, absolute, vacuum gage
85F: Gage, absolute		 0 - 1 to 500 psi (Absolute, gage: 82, 154N)
0 - 5 to 500 psi (Absolute, gage: 85, 86)
0 - 15 to 500 psi (85F, vacuum gage: 82, 85, 86, 154N)		 100 mV typical ±0.3% FSO (1 psi)
±0.2% FSO (5 psi)
±0.1% FSO (t15 psi)
±0.1% FSO (85F)		 82: Ø19 x 6.48
86: Ø15.82 x 11.4
154N: Ø18.97 x 13.8
85F: Ø17.2 x 11.33
85: Ø15.85 x 9.3
  • High performance
  • High stability for OEM applications
  • Minimizes trapped volume (85F)
DP86 O-Ring Mount,
with Fittings/Cable		 5/8" (16mm) Differential 0 - 1 to 500 psi 100 mV typical/sensitivity dependent ±0.3% FSO (1 psi)
±0.2% FSO (5 psi)
±0.1% FSO (≥15 psi)		 O-ring: Ø15.82 x 17.5
Fittings: Application dependent
  • Wet/wet differential pressure
  • Line pressure max. 1,000 psi
U86B Mountable with o-ring seal Sealed gage, absolute 0 - 5 to 13 bar/
0 - 50 to 200 psi		 0.5 - 4.5 VDC
(Ratiometric output)		 ±0.5% FSO Ø15.82 x 13.6
Socket spacing: 31.75
  • Amplified

Transducers and Transmitters

Category Product Type Pressure Range Output/Span Accuracy Dimensions
(mm)		 Agency Approvals Links
Industrial US300 Gage, absolute 0 - 15 to 5K psi 0 - 10 mV/V,
0.5 - 4.5 V, 1 - 5 V,
4 - 20 mA		 ±0.15% FSO (15 - 1K psi),
±0.25% FSO (>1K psi)		 15.88 x 15.88 x 98.00 -
Datasheets


Catalog
M3200 Gage, compound 0-7bar to 500 bar/
0-100 to 7,500 Psi		 100mV, 0.5 - 4.5 V, 1 - 5 V, 0 - 5 V, 0 - 10 V, 4 - 20 mA and I²C Digital Output ±0.25% FSO 22.2 on Hex x 58 max. CE (EMC)
M5200 Gage, sealed, compound 0 - 3.5 to 1K bar/
0 - 50 to 15K psi		 0.5 - 4.5 V, 1 - 5 V, 0 - 5 V, 0 - 10 V, 4 - 20 mA, 1 - 6 V ±0.25% FSO 24 X 24 X 82 max. CE (EMC)
U5200
U5300		 Gage, sealed, absolute, compound 0 - 0.14 to 700 bar/
0 - 2 to 10K psi		 0.5 - 4.5 V, 1 - 5 V, 0 - 5 V, 0 - 10 V, 4 - 20 mA, 1 - 6 V ±0.1% FSO
(>5 and d500 psi)		 24 X 24 X 82 max. CE (EMC), UL 508
D5100 Differential wet/wet 0 - 0.07 to 35 bar/
0 - 1 to 500 psi		 80 mV / 100 mV, 0.5 - 4.5 VDC, 1 - 5 VDC, 4 - 20 mA ±0.3% FSO (<5 psi),
±0.25% FSO (5 psi),
±0.1 % FSO (≥15 psi)		 25.4 x 58.4 x 72.0 CE (EMC)
Heavy Industrial M7100
U7100		 Gage, no vent gage (M7100)
Gage, sealed gage, absolute (U7100)		 0 - 10 to 700 bar/0 - 150 to 10K psi (M7100)
0 - 1 to 10 bar/0 - 15 to 150 psi (U7100)		 0.5 - 4.5 VDC [Ratiometric output]
1 - 5 VDC [Regulated] (M7100)
0.5 - 4.5 VDC [Ratiometric output] (U7100)		 0.25% FSO 26.7 x 26.7 x 50.0 CE (EMC), UL 508
P900, P981, P1200, P700, P9000 Gage, absolute 0 - 5 bar to 700 bar/
0 - 75 to 10K psi		 0 - 5 VDC, 0 - 10 VDC, 4 - 20 mA 0.1% to 0.2% FSO Application dependent CE, CENELEC (Intrinsically Safe)
P101
P105
P125		 Gage 0 - 10 to 7K bar/
0 - 150 to 100K psi		 7.5 to 20 mV (4 V; 5 V optional) ±0.3% FSO Ø29 x 85 max -
Miniature XP Gage, sealed, absolute 0 - 1 to 350 bar/0 - 15 to 5K psi (XP5, XPM10)
0 - 5 to 200 bar/0 - 75 to 3K psi (XPM4)
0 - 100 to 1K bar/0 - 1.5K to 15K psi (XPM6)		 20 - 100 mV, 4 V FSO (Amplified) Down to ±0.25% FSO (XP5, XPM6, XPM10)
down to ±0.35% FSO (XPM4)		 XPM4: M4 x 0.7 thread; Hex 8
XP5: M5 x 0.8 or 10-32 UNF thread; Hex 10
XPM6: M6 x 1 thread; Hex 12
XPM10: M10 x 1 thread; Hex 15		 -
XPC10 Gage, sealed, absolute 0 - 10 to 500 bar/
0 - 150 to 7.5K psi		 12 mV FSO, 4 V FSO (Amplified) Down to ±0.25% FSO M10 x 1 or 3/8-24 UNF thread; Hex 15 -
EB
EPRB		 Gage, sealed, absolute 0 - 0.35 to 700 bar/
0 - 5 to 10K psi		 0.5 to 4.5 VDC ±0.25% FSO 11 body diameter CE (EMC)
EPIH Gage, sealed, absolute 0 - 0.35 to 20 bar/
0 - 5 to 300 psi		 12 mV to 75 mV ±1.0% FSO Application dependent -
EPB
EPB-PW
EPL		 Gage, sealed, absolute 0 - 0.35 to 350 bar/
0 - 5 to 5K psi		 10 mV to 125 mV ±0.5 to ±1% FSO 3.2 to 7 outside diameter -
Liquid Level U5700 Gage, sealed, absolute, compound 0 - 2 to 10K psi 0.5 - 4.5 V, 1 - 5 V, 0 - 5 V, 0 - 10 V, 4 - 20 mA, 1 - 6 V 0.1 % FSO 22.23 x 22.23 x 98.04 CE (EMC)

IntraSense


Product Series Pressure Range Pressure Type Temp. Range Links
SMI-1A IntraSenseTM 0 to +1300mmHg Absolute 0°C to 105°C (customizable)
Datasheets


Presentations


Applications-Notes
SMI-1B IntraSenseTM
Lightshielded		 0 to +1300mmHg Absolute 0°C to 105°C (customizable)
SMI-1A IntraSenseTM
Calibrated		 -600 to +1300mmHg Absolute 0°C to 105°C (customizable)
SMI-1A IntraSenseTM
Calibrated
Lightshielded		 -600 to +1300mmHg Absolute 0°C to 105°C (customizable)

Digital & Analog Systems

Product Family Product Series Pressure Range Pressure Type Com. Temp. Range Package & Port Type Digital Interface Analog Output Supply Voltage Digital / Analog Accuracy Links
Low Pressure SM7X91 0.07-0.3 PSI Gauge, Differential, Asymmetric -20°C to +85°C SOIC-16 Dual Vertical or Dual Horizontal,
SOIC-10 Single Vertical		 I²C, 16 bit 10% to 90 % of VDD 3.3 / 5V 1% / 1.5% FS
Datasheets
SM6X91 0.3-0.8 PSI Gauge, Differential, Asymmetric -20°C to +85°C SOIC-16 Dual Vertical or Dual Horizontal,
SOIC-10 Single Vertical		 I²C, 16 bit 10% to 90 % of VDD 3.3 / 5V 1% / 1.5% FS
SM5X91 0.8-2.5 PSI Gauge, Differential, Asymmetric -20°C to +85°C SOIC-16 Dual Vertical or Dual Horizontal,
SOIC-10 Single Vertical		 I²C, 16 bit 10% to 90 % of VDD 3.3 / 5V 1% / 1.5% FS
Medium Pressure SM4X91 2.5-15 PSI Gauge, Differential, Asymmetric -20°C to +85°C SOIC-16 Dual Vertical or Dual Horizontal,
SOIC-10 Single Vertical		 I²C, 16 bit 10% to 90 % of VDD 3.3 / 5V 1% / 1.5% FS
SM1X91 0-15 PSI Gauge, Differential, Asymmetric -20°C to +85°C SOIC-16 Dual Vertical or Dual Horizontal,
SOIC-10 Single Vertical		 I²C, 16 bit 10% to 90 % of VDD 3.3 / 5V 1% / 1.5% FS

Digital Systems

Product Family Product Series AccuStable Pressure Range Pressure Type Com. Temp. Range Port Type Digital Interface Supply Voltage Accuracy Links
Ultra-Low Pressure SM933X - 0-125/250 Pa Differential -20°C to +85°C Dual Vertical I²C, 16 bit 3.3 V 1% FS
Datasheets
SM9543 - 5 mbar Differential -20°C to +85°C Dual Vertical I²C, 14 bit 3.3V 1.5% FS
Low Pressure SM7X21 √ 0.15-0.3 PSI Gauge, Differential, Asymmetric -20°C to +85°C Dual Vertical,
Dual Horizontal		 I²C, 14 bit 3.3 / 5V 1 % FS
SM6X21 √ 0.3-0.8 PSI Gauge, Differential, Asymmetric -20°C to +85°C Dual Vertical,
Dual Horizontal		 I²C, 14 bit 3.3 / 5V 1 % FS
SM5X21 √ 0.8-2.5 PSI Gauge, Differential, Asymmetric -20°C to +85°C Dual Vertical,
Dual Horizontal		 I²C, 14 bit 3.3 / 5V 1 % FS
Medium Pressure SM4X21 √ 2.5-15 PSI Gauge, Differential, Asymmetric -20°C to +85°C Dual Vertical,
Dual Horizontal		 I²C, 14 bit 3.3 / 5V 1 % FS
SM1X21 √ 15-30 PSI Gauge, Differential, Asymmetric -20°C to +85°C Dual Vertical,
Dual Horizontal		 I²C, 14 bit 3.3 / 5V 1 % FS

SM9333 / SM9336 Ultra-Low Differential Pressure Sensor for HVAC Applications
    Features:
  • Pressure ranges: ±125 and ±250 Pa Differential
  • SM9336 Accuracy after Autozero: < 1%FS
  • 16 bit I2C Digital interface
  • Pressure calibrated and temperature compensated output
  • Compensated temperature range: -20 to 85°C
    Why use SM9333 / SM9336 Pressure Sensors:
  • Ultra-Low pressure from 125 Pascal (0.50 in H2O)
  • High-performance detection in slightest pressure drops
  • Reduce utilization costs by identifying air leakage during operation
    HVAC Applications:
  • Flow Sensing Applications
  • Clogged Filter Detection
  • Variable Air Volume Control
  • Static Duct Pressure
  • Pressure Transmitters
  • Differential pressure for Stairwell Pressurization
Part Number Pressure Range b Voltage Shipping Comment
SM9333-BCE-S-125-000 -125 Pa to +125 Pa 3.3V Sticks (45 parts/stick) Bandwidth 20Hz a
SM9333-BCE-T-125-000 Tape and Reel (350 parts/reel)
SM9336-BCE-S-250-000 -250 Pa to +250 Pa 3.3V Sticks (45 parts/stick) Bandwidth 20Hz a
SM9336-BCE-T-250-000 Tape and Reel (350 parts/reel)

Uncompensated

Product Family Pressure Range Pressure Type Temp. Range Package Type Port Type Links
SM9G/D
Uncompensated Low Pressure		 0.3 to 1.5 PSI Gauge, Differential -40°C to +125°C SOIC16 Single Horizontal, Dual Horizontal,
Single Vertical, Dual Vertical
Datasheets
SM5G Gauge
Medium Pressure Sensor		 5 to 80 PSI Gauge -40°C to +125°C SOIC8 Gauge Single Vertical
SM5420E
Absolute Pressure Sensor		 15 to 100 PSI Absolute -40°C to +125°C SOIC Absolute Hole, Single Vertical

Available Packages:

  • Uncompensated & compensated packaged Die
  • Pressure Range from 0.15 to 100PSI (1mbar to 6.9 bar)
  • Pressure Type Absolute, Gauge or Differential
  • Operating Temperature Range from -40°C up to +125°C

AccuStable:

  • All Products which earned the AccuStableTM Label
    • Have guaranteed Span and Offset Shift <1% over the life span of the product
    • Based on 1000 hours of high temperature operating life (HTOL) testing
  • Compensated System which earned the AccuStableTM Label
    • Additionally have a guaranteed total Accuracy Error < 1%
    • Which combines linearity, hysteresis and stability
    • Applies over all operating conditions


Rate and Inertial Sensors

Rate Sensors and Gyros

Products Package FS Range Unique Features Accuracy Excitation Voltage Operating Temp. Dimensions
(mm)		 Links
11206AC Electroless nickel plated Aluminum ±50, ±180°/sec
  • IdentiCal™ interchangeable sensor
  • ±0.5% accuracy from -40°C to +85°C
  • Silicon MEMS gyro
  • EN61000-6-2/-4 certified for industrial environment
 ±0.1% non-linearity 8.5 - 36VDC -40°C to 85°C 24 x 24 x 27.30
Datasheets


Catalog
11207AC Electroless nickel plated Aluminum ±300°/sec
  • IdentiCal™ interchangeable sensor
  • High stability
  • Low noise
  • Vibration-rejecting
 ±0.01% non-linearity 10 - 36VDC -40°C to 85°C 24 x 24 x 27.30
31206B / 31207B Electroless nickel plated Aluminum ±50, ±180, ±1000°/sec
  • Triaxial angular rate sensor
  • Stable performance over temperature
  • Power supply regulation
  • Temperature calibration data
 ±0.1% non-linearity 8.5-36VDC -40°C to 85°C 24 x 24 x 28.30
610 Anodized aluminum ±500 to ±50K°/sec
  • Small, lightweight package
  • SAE-J211, ISO-6487, NHTSA approved
  • Crash testing certified
  • Insensitive to shock
 ±0.5% non-linearity 5 - 16VDC -40°C to 105°C 14.6 x 10.2 x 7.6
603 Anodized aluminum ±100 to ±24K°/sec
  • MEMS triaxial rate sensor
  • SAEJ211 compliant
  • Shock resistant housing
  • Rugged compact package
 ±0.5% non-linearity 5 - 16VDC -40°C to 105°C 20.8 x 20.8 x 14.5

6 Degrees of Freedom Sensors

Products Package FS Ranges Unique Features Accuracy Excitation Voltage Operating Temp. Dimensions
(mm)		 Datasheets
633 Stainless steel ±500 to ±50K°/sec
±50g to ±6,000g
  • Complete six degree-of-freedom (6DoF) analog sensor
  • Shock resistant rugged housing
  • Silicon MEMS gyros
  • PR MEMS high-g shock sensors
 ±0.5% non-linearity 5 - 16VDC -40°C to 105°C 21.3 x 21.3 x 15.2
Datasheets


Catalog
634 Anodized aluminum ±100 to ±18K°/sec
±2g to ±100g
  • 6DoF analog sensor
  • Signal conditioned output
  • Silicon MEMS gyros
  • UltraStable VC MEMS low-g sensors
 ±0.1% non-linearity 5 - 16VDC -40°C to 105°C 30.5 x 30.5 x 24.6

Temperature Sensors


Flyer Temperature Sensor Overview

Sensing Elements - NTC

Products Package Type Resistance Range Unique Features Accuracy Operating Temp. Dimensions Links
Thermistor Chips Leadless chips, SMD 0402, 0603, 0805 Gold or silver electrodes, surface mounted Chip: 100 to 1MΩ/
SMD:2K to 200KΩ
  • Wire bonding compatible
  • End band SMD
 ±1% to 10% -40°C to 125°C Chip: 0.34 - 1 square
SMD 0402: 1 x 0.5 x 0.7
SMD 0603: 1.6 x 0.8 x 1
SMD 0805: 2 x 1.25 x 1.2
Datasheets


Catalog
Radial Leaded Thermistors Radial, beads Epoxy or glass coated 100 to 1MΩ
  • Interchangeable
  • Moisture resistant
  • Stability
 0.25% to 20% -55°C to 280°C 0.4 to 4.9
Axial Leaded Thermistors DO-35 Glass coated 5KΩ to 100KΩ
  • Tight tolerance (±1%)
  • Max. stability using high density (HD) chip
  • Hermetically sealed
  • Tinned and nickel plated leads
 ±1% to ±3% -40°C to 300°C 2.0 x 4.0 body
Space Qualified
(Hi-Rel)		 Radial, bead, custom NTC, epoxy, glass, probes 1KΩ to 100KΩ
  • ESA and NASA approved
  • High reliability and accuracy
 0.5% to 10% -55°C to 160°C From 2.4

Sensing Elements - Digital

Product Package Type Unique Features Accuracy Operating Temp. Dimensions
(mm)		 Links
Temperature System Sensor
(TSYS)		 QFN16, TDFN8 I²C, SPI
  • Low power
  • Small size
  • Calibrated and ready to use
  • 16-bit resolution
 Up to ±0.1°C at -5°C to 50°C -40°C to 125°C QFN16: 4 x 4 x 0.85
TDFN8: 2.5 x 2.5 x 0.75
Datasheets


Catalog

Sensing Elements - RTD

Product Package Type Resistance Range Unique Features Accuracy Dimensions
(mm)		 Links
Nickel RTD SOT 23
Bare die on request
  • Thin film nickel structure on silicon substrate, protected with a passivation layer
  • SOT 23 package for SMT
  • Bare die for COB assembly
 1,000Ω
  • Harsh environment compatible
  • Automotive qualified
  • Very small dimensions
  • Very short response time
  • Good linearity
  • High temperature coefficient
  • Low power consumption
  • Good thermal connection of sensing element through leadframe-pin
 Class B, according to former DIN 43760 standard 2.1 x 2.5 x 2.1 (SOT 23)
0.7 x 0.7 x 0.4 (Bare die)
Datasheets


Catalog
Platinum Thin Film Chips Leadless chips, SMD 1206
  • Thin film platinum deposited on ceramic substrate
  • Contact pads on top and bottom side for NTC chip like assembly
  • Contact pads on both ends for SMT
 100Ω, 1,000Ω (Other values on request)
  • Long term stability
  • Interchangeability
  • Assembly like NTC chips
  • Very small dimensions
  • Short response time
 According to DIN EN 60751 1.5 x 1.5 (Top/bottom pads)
1.2 x 3.6 (SMT)
Platinum Thin Film Sensors Wired component
  • Thin film platinum deposited on ceramic substrate, glass coated
  • Tube outline available
  • Connection via radial leads
 100Ω, 1,000Ω (Other values on request)
  • Long term stability
  • Interchangeability
  • Small dimensions
  • Short response time
  • High electrical insulation
 Class T (F0.1), A (F0.15), B (F0.3) according to DIN EN 60751 2.0 x 2.3 x 1.1 (Standard)
1.2 x 4.0 x 1.1 (Standard)
Other dimensions (On request)
Glass Wire Wound Sensors GO, GX
  • Glass rod, radial leads
 100Ω (2X 100Ω on few versions)
  • Aggressive environments (Acid, oil, solvent)
  • Small dimensions
  • Stability
  • No hysteresis
  • Short response time
  • Interchangeability
 Class W0.3, W0.15, W0.1 according to IEC60751 Ø1.8/length 5 mm to Ø4.5/length 48 mm
Ceramic Wire Wound Sensors CWW600, CWW850, CWW1000
  • Ceramic rod, radial leads
 100Ω (2X 100Ω on few versions)
  • High temperature
  • Stability
  • No hysteresis
  • Small dimension
  • Interchangeability
 Class W0.3, W0.15, W0.1 according to IEC60751 Ø1.5/length 8 mm to
Ø4.5/length 30 mm
Ø2.7/length 45 mm (CWW1000)

Sensor Assemblies

Product Package Type Unique Features Dimensions
(mm)		 Links
Ring Sensors Ring for surface assembly Threaded bolt, tube style Epoxy potted element
  • Surface mount sensing
  • For use where space is limited
  • Simple installation
 Case specific dimensions
Datasheets


Catalog
Push-in Sensors Brass, copper or stainless steel closed-end tube Epoxy potted element, miniature design
  • Corrosion resistant
  • Available with mounting tabs or clips
 Case specific dimensions
Screw-in Sensors Brass, copper or stainless steel housing with integrated connector Epoxy potted element, rigid sheath
  • Corrosion resistant
  • Different thread types
  • Connectors available
 Custom lengths, diameters and threads available
Refrigeration Molded Probes PVC or TPE Overmolded
  • Mounting clips available
 8 x 30, 6.5 x 25, 6 x 50, 6 x 5 x 15
Pipe Mount Sensors Copper or stainless steel housing
  • Overmolded
  • Epoxy potted
  • Fast response time
  • Moisture resistant construction
 Custom configurations available
Outdoor Air Sensors Metal housing with PVC sun shield with or without weatherproof box Fast response time
  • Easy installation – threads into mounting hole or standard handy box
  • Fully potted housing protects sensing element and provides fast, accurate response
 Ø12 X 64
Pool and Spa Sensors Plastic or metal housing with o-ring seal designed for band clamp or backing nut Overmolded subassembly
  • O-ring seals
  • Compatible with pool and spa chemicals
 6.4 x 50
Boiler Sensors Brass or SS housing Threaded housing
  • Integrated connector
  • Corrosion resistant
  • Different threads types and connectors available
 Custom lengths, diameters and threads available
Oven Sensors Stainless steel housing
  • Pt element encapsulated into ceramic tube, with rigid stainless steel housing
  • High temperature cable
  • High temperature
  • Easy integration/installation
  • Higher dielectric strength according to type
 OD Ø4 mm to Ø6 mm
Immersion length 35 mm to 100 mm
Custom mechanical interface and cable length
Urea Temperature Sensors Plastic housing with screw hole mountings Overmolded plastic housing with integrated 2 pin connector
  • Temperature measurement of urea liquid used in Selective Catalytic Reduction (SCR) systems
  • Suitable for high pressure applications
 Sensor tip 8 mm diameter
Exhaust Gas Temperature Probes EGT thermocouple probe
  • Mineral insulated alloy sheath, screwed mechanical interface, cable extension and automotive connector
  • Option: CANbus interface (From 1 to 4 thermocouples, fully configurable)
  • High temperature, robust design
  • Vibration and corrosion resistant
  • Fast response time
  • OD Ø4 to OD Ø8
  • Custom immersion length and cable length
Micro-Thermocouples Fine gage thermocouples
  • Micro sized thermocouple: 44 AWG, 40 AWG, 38 AWG, 36 AWG
  • Polymer encapsulated or bare junction
  • Welded or soldered junction
  • Low profile, fast response
  • Polyesterimide wire insulation
 Varies by thermocouple gage
Patient Monitoring Probes Sensor with cable and connector Reusable: Skin; 10FR and 12FR GP
Disposable: Skin; 9FR and 12FR GP; 12FR, 18FR, 24FR Esoph/
Stethoscope; 14FR, 16FR, 18FR Foley catheter
  • Autoclavable reusables
  • Sterile disposables
 Reusable: 3 m cable with sensor Disposable: Sensor <1 m; 3 m reusable adaptor cable
TLH Reference Probe TLH100/TLH600 Rigid protective external stainless steel sheath and stainless steel handle, unique internal design to insure stability
  • Stability
  • Provided with calibration report or option of calibration certificate by national committee for accreditation (COFRAC)
 OD Ø5 x 500 + handle Ø15 x 100 (Typical cable length = 2 m)
USB Temperature Probe Push-in probe with handle
  • Versatile push-in probe with stainless steel sheath and plastic or stainless steel handle
  • High precision sensing element combined with integrated electronics for signal processing, calibration and USB interface
  • USB conformal interface
  • Calibrated digital output, recalibration possible on request
  • Robust design for general purpose applications
  • Long term stability
 OD Ø6 x 200 + handle Ø19 x 100 (Typical cable length = 2,000)
Stator Sensors TPE/CPME
G11 epoxy glass laminated, Class F or H
  • Rigid flat, slot sensor
  • Cable or leadwire options
  • Extended sensitive length
  • Single or dual elements
  • Calibration available
 Custom dimensions available
Surface Sensors Silicone rubber or polyimide laminated element SP683
  • Flat, flexible, rectangular sensor
  • Variety of designs available
  • Surface sensing for curved or uneven surfaces
  • Noninvasive, simple installation
  • Adhesive backing option
 Custom dimensions available
Bearing Sensors Copper alloy tip Stainless steel, isolated stainless steel or epoxy glass case
  • Rigid sheath
  • Tip sensitive
  • Cable/leadwire options
  • Cut-to-length
  • Copper tip for fast time response
  • Assemblies with fluid seal and spring loading
  • Single or dual elements
 Custom lengths Standard sheath diameters: Ø4.78, Ø5.46, Ø6.35
Thermocouple Screw-in or push-in design with cable extension, connector, or connecting head
  • Collapsible Mineral Insulated (MI) with alloy sheath (Radius ≥5*OD)
  • Flexible cable with plastic or composite insulation
  • Rigid protection sheath: ceramic, quartz or alloy sheath
  • High temperature and high vibration level (For MI)
  • Available in small diameters for fast respond time
  • Grounded or ungrounded or apparent hot junction
  • Single or multiple measuring points
  • OD Ø0.3 mm to Ø8 mm for MI
  • Ø0.15 mm for smallest flexible cable
  • Custom dimensions, fittings and cable lengths
    (From few centimeters to many meters)
Transmitter Brass, copper and stainless steel housing, flexible sheath with integrated connector.
  • Epoxy potted element
  • Screw-in
  • Compact, welded design
  • Highly sensitive and stable
  • High vibration application
  • Good waterproof properties
  • Customer sheath length, thread type
  • Probe diameter: Ø4.75 mm; Ø5 mm; Ø6 mm; Ø6.35 mm; Ø8 mm

Thermopiles

Product Package Type Unique Features Accuracy Dimensions
(mm)		 Links
TS TO-18, TO-5 Thermopile sensor components
  • High signal output
  • Accurate reference sensors
 Depends on applied electronics and calibration Ø9.15 x 4.4 (Body)
Datasheets


Catalog
TSD TO-5 Digital thermopile sensor component
  • Calibrated and ready to use, I²C interface
  • Direct assembly to PCB, no additional components needed
 Depends on temperature range, typical 1% full range Ø9.15 x 4.4 (Body)

Thermocouples

Types Features Links
Thermocouple Assembly
  • Wide operating temperature range
  • Relatively constant sensitivity over their entire range
  • Industry standard output signals
  • Most popular alloy types available
  • Wide range of sizes available, from micro to heavy industrial
  • Metal sheathing and industrial connection head options
  • Full range of motor/generator and plastic industry styles
Explosion Proof Thermocouple Sensors
Industrial Thermocouple Sensors
Stator Thermocouples
Micro-Thermocouples
Tip Sensitive Thermocouples

Digital Component Sensor Development Tools

Wireless Demo and Development Kits

Product Type Specifications Communication
Interface		 Application Operating Temp. Links
Environmental Sensor Tag Humidity,
Temperature,
Pressure
  • 0 - 100% RH
  • 300 to 1,200 mbar
 Standard 2.4 GHz wireless communication iOS 7.0+ Android™ 4.3+ 20°C to 85°C
Datasheets


Catalog
M5600 Pressure
  • 50 - 15K psi
  • Type G/S/C
 Standard 2.4 GHz wireless communication iOS 7.0+ Android™ 4.3+ -20°C to 85°C
U5600 Pressure
  • 2 - 10K psi
  • Type G/S/C/A
 Standard 2.4 GHz wireless communication iOS 7.0+ Android™ 4.3+ -20°C to 85°C

Shields and Hats

Product Type Sensors Specifications Communication Interface Partner Board Links
Arduino Weather Shield Humidity,
Temperature,
Pressure		 HTU21D, MS5637, MS8607, TSYS01, TSD305
  • 0 - 100% RH
  • 20°C to 85°C
  • 300 to 1,200 mbar
 I²C Arduino / Genuino
Datasheets


Catalog
Raspberry PiTM Sensors Weather Hat Humidity,
Temperature,
Pressure		 HTU21D, MS5637, TSYS01, TSD305
  • 0 - 100% RH
  • 20°C to 85°C
  • 300 to 1,200 mbar
 I²C Raspberry PiTM
PicTail Plus Humidity,
Temperature,
Pressure		 HTU21DF, MS5637, TSYS01, MS8607
  • 0 - 100% RH
  • 20°C to 85°C
  • 300 to 1,200 mbar
 I²C Microchip Explorer 16

Wing Boards

Product Type Specifications Accuracy Commnication Interface Compatibility Links
HTU21D Humidity
  • 0 to 100% RH
  • -40°C to 125°C
  • 3.3 to 5.5 V
 ±3% RH I²C Configured to operate with the Xplained Pro development platform
Datasheets


Catalog
MS5637 Pressure
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 1.5 to 3.6 V
 ±2 mbar
MS8607 Pressure,
Temperature,
Humidity
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 0 to 100% RH
  • 1.5 to 3.6 V
 ±3% RH,
±2 mbar
±1.0°C
TSYS01 Temperature
  • -40°C to 125°C
  • 2.2 to 3.6 V
 ±0.1°C
TSYS02D Temperature
  • -40°C to 125°C
  • 1.5 to 3.6 V
 ±0.2°C
KMA226(A) Angular Position
  • 0 to 360°
  • -25°C to 85°C
  • 2.9 to 6.0 V
 ±0.2°C

Peripheral Modules

Product Type Specifications Accuracy Communication
Interface		 Compatibility Links
HTU21D Humidity
  • 0 to 100% RH
  • -40°C to 125°C
  • 3.3 to 5.5 V
 ±3% RH I²C Development systems compatible with Digilent Pmod™ connections
Datasheets


Catalog
MS5637 Pressure
  • 10 to 2000 mbar
  • -40°C to 85°C
  • 1.5 to 3.6 V
 ±2 mbar
MS8607 Pressure,
Temperature,
Humidity
  • 10 to 2000 mbar
  • -40°C to 85°C
  • 0 to 100% RH
  • 1.5 to 3.6 V
 ±3% RH,
±2 mbar,
±1.0°C
TSYS01 Temperature
  • -40°C to 125°C
  • 2.2 to 3.6 V
 ±0.1°C
TSYS02D Temperature
  • -40°C to 125°C
  • 1.5 to 3.6 V
 ±0.2°C
KMA26(A) Angular Position
  • 0° to 360°
  • -25°C to 85°C
  • 2.9 to 6.0 V
 ±0.1°C
MS5611 Pressure
  • 10 to 1,200 mbar
  • -40°C to 85°C
  • 1.5 to 3.6 V
 ±2 mbar
MS5837 Pressure
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 1.5 to 3.6 V
 ±2 mbar
MS5805 Pressure
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 1.8 to 3.6 V
 ±2 mbar
TSD305 Temperature
  • -10°C to +85°C
  • 1.68 to 3.6 V
 ±1°C

Grove System

Product Type Specifications Accuracy Comm. Interface Compatibility Links
KMA36 Angular Position
  • 0 to 360°
  • -25°C to 85°C
  • 5.0 V
 ±0.1°C I²C Development platform compatible with grove system
Datasheets


Catalog
TSYS01 Temperature
  • -40°C to 125°C
  • 5.0 V
 ±0.1°C
TSYS02 Temperature
  • -40°C to 125°C
  • 5.0 V
 ±0.2°C
MS5637 Pressure
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 5.0 V
 ±2 mbar
MS8607 Pressure,
Temperature,
Humidity
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 0 to 100% RH
  • 5.0 V
 ±3% RH,
±2 mbar,
±1.0°C
HTU21D Humidity
  • 0 to 100% RH
  • -40°C to 125°C
  • 5.0 V
 ±3% RH
MS5611 Pressure
  • 10 to 1,200 mbar
  • -40°C to 85°C
  • 5.0 V
 ±2mbar
MS5837 Pressure
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 5.0 V
 ±2mbar
MS5805 Pressure
  • 10 to 2,000 mbar
  • -40°C to 85°C
  • 5.0 V
 ±2 mbar
TSD305 Temperature
  • -10°C to +85°C
  • 5.0 V
 ±1°C

Applications

Industries & Solutions Picture Applications
Aerospace
  • Urban Air Mobility
  • Grounding Systems
  • Cabin Interiors and In-Flight Entertainment
  • Avionics
  • Weapons and Munitions
  • Propulsion and Power Distribution
  • EWIS – SWAMP
  • Flight Control and Landing Gear Systems for Commercial Aerospace
Appliances
  • Small Home Appliances
  • Washer and Dryers Applications
  • Refrigeration Applications
  • Dishwashers Applications
  • Cooking Applications
  • Air Conditioning Applications
Automation & Control
  • Ethernet
  • Motor Connectivity
  • Servo Drives
  • Motor Connectivity Visual
  • Programmable Logic Controller
  • I/O Module
  • HMI/CNC
Automotive
  • Battery Management Systems
  • Automotive Data Connectivity Safety
  • Automotive Data Connectivity Infotainment
  • Automotive Data Connectivity In-Vehicle Networks
  • Solutions for Miniaturization
  • Solutions for CO2 Emission Reduction
  • Power Connectivity
Autosport
  • Data Acquisition
  • Power Generation
Communications & Wireless Equipment
  • Remote Radio Units
  • Baseband Units and Optical Transport
  • Base Station and Optical Transport
  • Access Equipment
Connected Home
  • Lawn and Garden
  • Low Power and Signal Applications
  • TV and Set Top Box
  • Tablets
  • Smartphones
  • Connected Home Products
Consumer Solutions
  • Virtual Reality and Augmented Reality
  • Commercial and Consumer Drones
  • Printers and Copiers
  • Digital Still and Video Camera
  • Gaming
  • TV and Set Top Box
  • Notebooks and Ultraportable Devices
  • Tablets
  • Smartphones
  • Wearables
Data Centers
  • DataRack
  • Storage Solutions
  • Server Solutions
  • Switching and Routing
Defense & Military
  • Unmanned Vehicles
  • Solutions for Space
  • Solutions for Rugged Embedded Computing
  • Weapons Systems
  • Warheads
  • Soldier Systems Wearables
  • Spacecraft Chassis
  • Space Launch Vehicle
  • Space Qualified C4ISR Systems
  • Soldier Weapons Systems
  • Seeker and Guidance
  • Power Distribution
  • Military Marine: Submarine Solutions
  • Military Marine: Propulsion and Power Distribution
  • Military Marine Solutions
Energy & Utilities
  • Underground Power Network Connectivity
  • Overhead Electrical Systems Connectivity
  • Substation Solutions
  • Wind Energy Solutions
  • Solar Energy Solutions
  • Data Center Connectivity
  • Wildfire Mitigation Systems
  • Railway Solutions
Hybrid & Electric Mobility
  • Electrification of Commercial Vehicles
  • In-Vehicle Technologies
  • Charging Inlets
  • Battery Connection
Industrial Machinery
  • Robot Control
  • Moling Machine
  • Control Cabinet
  • Robot Arm
  • Machine Tool
Intelligent Buildings
  • Building Automation & Lighting
  • Outdoor Lighting
  • Horticultural Lighting
  • Street & Area Lighting
  • Indoor Lighting
  • Environmental comfort HVAC
  • Elevators & Escalator Solutions
  • Safety & Security Solutions for Intelligent Buildings
Medical & Healthcare
  • Personal Health
  • Ventilators
  • Medical Balloons
  • Laser Processing
  • Advanced Catheter Systems
  • Custom Extrusions
  • Custom Catheter Shafts
  • Custom Guidewire Manufacturing
  • Ultrasound Cable Assembly
  • Reusable Surgical Cable Assembly
  • Patient Monitoring Cable Assembly
  • Interventional Catheter Assembly
  • High Volume Assemblies
  • High Energy Therapeutic Cable Assembly
  • COMFORT+ Cable Standard Ultrasound Sub-Assembly
Oil & Gas / Marine
  • ROV/AUV
  • Oil and Gas
  • Sewer and Waste Water Industries
  • Oceanographic
  • Environmental
  • Defense and Military
  • Shipbuilding and Offshore Solutions
  • High Performance Petrochemical Solutions
  • Topside Communication & Controls
  • Subsea Production
  • Subsea Drilling
  • Marine Control Communications
Rail
  • Data Communications
  • Electrified Railways
  • Rail roofline Solutions
  • Power and Signal
Sensor Solutions
  • Consumer Sensor Applications
  • Hydraulic LVDT Sensors
  • Force Sensors for Aerospace Applications
  • Railway Sensors
  • IoT Sensors
  • Drone Sensors
  • Wind Turbine Sensors
  • Automotive Sensors
  • Automation & Process Control Sensors
  • Environmental Monitoring Sensor Applications
  • HVACR and Building Equipment Sensor Applications
  • Test and Measurement Sensor Applications
  • Truck/Bus/Off Road Vehicle Sensors
  • Industrial Sensors
  • Oil, Gas, and Marine Sensor Applications
Truck, Bus & Off-Road Vehicles
  • Data Connectivity Solutions
  • Motor Bike
  • Solutions for Marine Applications
  • Solutions for J1939 Specifications
  • Solutions for Construction Applications
  • Environmentally Sealed Solutions
